Commvault validated reference design specification for Cisco UCS S3260 M5
Commvault HyperScale™ Software on Cisco® UCS® S3260 M5
Introduction to Commvault HyperScale Software
With Commvault HyperScale™ Software, you can build a unified, modern data protection and management platform that delivers cloud-like services on-premises. The purpose of this technical specification is to detail the Cisco® UCS® S3260 M5 Storage Server for the Commvault Validated Reference Design. By building these services on a scale-out infrastructure and leveraging Commvault capabilities, you’ll enable:
- Cloud-like agility, resiliency and availability to on-premises data and applications
- Greater end-user efficiency through automation and self-service capabilities
- Improved hardware utilization and optimized costs from general-purpose hardware
- Seamless storage scalability with predictable performance without requiring forklift upgrades
- Better, more secure data protection, utilization and movement by eliminating point product and data silos
By shifting the secondary storage and data management infrastructure to this architecture, enterprises can go a long way in transforming their data centers to be as operationally efficient, resilient and scalable as public cloud infrastructure. Lower hardware costs, operational efficiencies and simplified support allows the replacement of limited and legacy backup tools with a modern cloud enabled data management solution at the cost of replacing legacy purpose-built backup appliance (PBBA). More important, this architecture, which extends into public cloud, allows enterprises to offer consistent sets of services to all workloads running on-premises or in public cloud, independent of the underlying infrastructure for true cloud based data management.
Reference design with Cisco
Cisco UCS S3260 M5 Storage Server is a modular dual-node server that provides architectural flexibility and is well-suited for high-capacity storage and I/O intensive workloads. Cisco UCS S3260 M5 Storage Servers can house two (2) nodes in an individual chassis, this density allows for two (2) Commvault HyperScale™ nodes to be housed in a single chassis. Cisco UCS S3260 M5 Storage Servers can be deployed as standalone servers or as part of the Cisco Unified Computing System to take advanced of Cisco standards-based unified computing innovations that help reduce customers’ total cost of ownership and increase business agility. The UCS S3260 M5 represents a suited platform for Commvault HyperScale™ Software to expand and transform capabilities for customers in today’s evolving software-defined world.
How to use this document
This document covers the design components of the Commvault HyperScale architecture, providing options for purchasing the infrastructure for a Commvault HyperScale Software solution. Commvault Validated Reference Designs deliver tested configurations with leading hardware vendor technology that provide validated designs complemented by best practices that will accelerate ROI, reduce complexity, and add customer value.
The document is broken into a high level component section detailing out the configuration and specific component options that can be selected depending on the storage density, metadata, and optional I/O components that are required. Each subsection provides guidance for ordering configurations.
This document does not cover overall architecture and design of the Commvault HyperScale solution, and should be considered as a supplement specific to Cisco.
Cisco UCS S3260 M5 specification summary
Core components
Core Components represent features of the build that do not change. They include Chassis, CPU, Memory, and other critical elements that need to be ordered.
Country-specific components such as power cables are not listed and can be changed as required.
| Core components | Technical specifications |
|---|---|
| Form factor | 4U Rackmount |
| Node form factor | Large Density – Single or Dual Node Capable |
| Motherboard chipset | Intel® C620 |
| Processors | Intel® Xeon® 4210R |
| Memory | 256 GB RAM (8x 32 GB RDIMM) |
| Networking | Cisco VIC 1300 Dual Port 40 GB QSFP CNA |
| Storage controller | Cisco 12G Modular SAS RAID |
Boot and metadata storage options
Boot storage houses the operating system and core Commvault HyperScale™ binaries, while the Metadata storage provides caching areas for such operations as deduplication, indexing, and extents.
| Boot/metadata configurations | Technical specifications |
|---|---|
| Separate boot/metadata Boot storage Metadata storage | 2x 480 GB SATA SSD, RAID1 4x Top Load 1.6 TB SSD Raid 5 |
Data storage options
Data storage houses the data footprint for the customer environment. Data storage configuration directly impacts the amount of data that each node in the solution is able to store.
When deploying nodes inside of the same block (e.g. 3 node initial configuration), choose identical HDDs. If the nodes in a block have different HDD sizes, the lowest size will be chosen for the data storage, which would lead to underutilized resources on nodes with larger HDDs.
Separate node blocks in the same grid may use different HDDs (e.g. mixing a 3 node 6TB block with a second 3 node 10TB block in the same grid).
Overall sizing and retention varies per customer and therefore is beyond the scope of this document. Please refer to Commvault HyperScale™ sizing documentation to determine the drive size (and node quantity) required for the specific deployment.
| Data storage configuration | Technical specification |
|---|---|
| Storage configuration – data storage Storage type | 4 TB, NL-SAS or SATA, 24 Drives 6 TB, NL-SAS or SATA, 24 Drives 8 TB, NL-SAS or SATA, 24 Drives 10 TB, NL-SAS or SATA, 24 Drives 12 TB, NL-SAS or SATA, 24 Drives 14 TB, NL-SAS or SATA, 24 drives |
Bill of materials
Commvault has partnered with Cisco to create Solution IDs which are pre-validated Bill of Materials (BOMs) that allows easy quoting by Cisco or a Cisco Reseller while ensuring the configurations are validated and consistent. These Solution IDs include the core hardware components for the Commvault HyperScale™ designs, items such as power cords and country specific region kits are required as part of the ordering process through the Cisco Commerce Workspace (CCW) website.
Note: ScaleProtect™ refers to the joint offering that Cisco and Commvault have in market. ScaleProtect™ with Cisco UCS® is Commvault data protection solution including Commvault HyperScale™ Software running on Cisco UCS infrastructure. The Commvault Validated Reference Design for Cisco UCS Servers utilizes the exact same infrastructure as the ScaleProtect offering.
Solution ID
Each Solution ID below represents either a single or dual Commvault HyperScale™ node configuration. The Dual Node configurations have a trailing “2N” on the end of the Solution ID.
Commvault HyperScale™ block sizes are made up of 3 or 6 node configurations, and as outlined in the Data Storage Options section, mixing and matching different nodes sizes within a block is not allowed.
To size a 3 node configuration, choose a single and a double node configuration. For instance if choosing 3 Nodes with 4TB drives, choose the “Commvault ScaleProtect S3260 M5 4TB” and “Commvault ScaleProtect S3260 M5 4TB 2N” Solution IDs.
To size a 6 node configuration, choose three double node configurations. For instance if choosing 6 nodes with 10TB drives, choose the “Commvault ScaleProtect S3260 M5 10TB 2N” with quantity 3.
| Qty. | Part number | Description |
|---|---|---|
| 1 | CVLT ScaleProtect S3260 M5 4 TB | S3260 M5 Single HyperScale™ Node with 24 x 4 TB Drives |
| 1 | CVLT ScaleProtect S3260 M5 4 TB 2N | S3260 M5 Dual HyperScale ™ Nodes with 48 x 4 TB Drives |
| 1 | CVLT ScaleProtect S3260 M5 6 TB | S3260 M5 Single HyperScale ™ Node with 24 x 6 TB Drives |
| 1 | CVLT ScaleProtect S3260 M5 6 TB 2N | S3260 M5 Dual HyperScale ™ Nodes with 48 x 6 TB Drives |
| 1 | CVLT ScaleProtect S3260 M5 8 TB | S3260 M5 Single HyperScale™ Node with 24 x 8 TB Drives |
| 1 | CVLT ScaleProtect S3260 M5 8 TB 2N | S3260 M5 Dual HyperScale ™ Nodes with 48 x 8 TB Drives |
| 1 | CVLT ScaleProtect S3260 M5 10 TB | S3260 M5 Single HyperScale™ Node with 24 x 10 TB Drives |
| 1 | CVLT ScaleProtect S3260 M5 10 TB 2N | S3260 M5 Dual HyperScale™ Nodes with 48 x 10 TB Drives |
| 1 | CVLT ScaleProtect S3260 M5 12 TB | S3260 M5 Single HyperScale ™ Node with 24 x 12 TB Drives |
| 1 | CVLT ScaleProtect S3260 M5 12 TB 2N | S3260 M5 Dual HyperScale™ Nodes with 48 x 12 TB Drives |
| 1 | CVLT ScaleProtect S3260 M5 14 TB | S3260 M5 Dual HyperScale™ Nodes with 24 x 14 TB Drives |
| 1 | CVLT ScaleProtect S3260 M5 14 TB 2N | S3260 M5 Dual HyperScale™ Nodes with 48 x 14 TB Drives |
Optional cloud cache
The following part numbers add optional Cloud Cache in the HyperScale Reference Design. The quantities below represent matching requirements for either a single or dual Commvault HyperScale node configuration.
These quantities represent a per node requirement and need to be added to each configuration.
To add Cloud Cache to a 3 node configuration, add quantity 1 NVMe to the 1 node configuration, such as the “CVLT ScaleProtect S3260 M5 4TB” and add quantity 2 NVMe to the 2 node, such as “CVLT ScaleProtect S3260 M5 4TB 2N”.
To size a 6 node configuration, add quantity 2 NVMe to each of the “CVLT ScaleProtect S3260 M5 10TB 2N”.
Option 1 – cloud cache
| Qty. | Part number | Description |
|---|---|---|
| 1 | UCS-S3260-NVG220 | Cisco UCS 2 TB NVMe – For Single Node Configurations |
| 2 | UCS-S3260-NVG220 | Cisco UCS 2 TB NVMe – For Dual Node Configurations |
Additional resources
Additional information regarding the Cisco UCS S3260 M5 can be found on the Cisco website.
A couple of useful links have been included:
- Cisco UCS S3260 Storage Server Data Sheet (U.S. version)
- Cisco UCS S3260 Storage Server Specification Sheet (U.S. version)
- The Cisco Commerce Workspace (CCW)
Commvault HyperScale Technology integrates with storage arrays, hypervisors, applications and the full range of cloud provider solu-tions to support the most diverse and dynamic environments.
